snapshot_prefix | string[16] | Snapshot1_ | 6/6 | Indicate the prefix of the filename. |
|
|
|
| media_i0=> Snapshot1_ |
|
|
|
| media_i1=> Snapshot2_ |
|
|
|
| media_i2=> Snapshot3_ |
|
|
|
| media_i3=> Snapshot4_ |
|
|
|
| media_i4=> Snapshot5_ |
|
|
|
|
|
snapshot_datesuffix | 0, 1 | 0 | 6/6 | Add date and time suffix to filename: |
|
|
|
| 1 = Add date and time suffix. |
|
|
|
| 0 = Do not add. |
|
|
|
|
|
snapshot_preevent | 0 ~ 7 | 1 | 6/6 | Indicates the number of |
|
|
|
| images. |
|
|
|
|
|
snapshot_postevent | 0 ~ 7 | 1 | 6/6 | The number of |
|
|
|
|
|
videoclip_source | <integer> | 0 | 6/6 | Indicate the source of media stream. |
|
|
|
| 0 means the first stream. |
|
|
|
| 1 means the second stream and etc. |
|
|
|
| 2 means the third stream and etc. |
|
|
|
| 3 means the fourth stream and etc. |
|
|
|
|
|
videoclip_prefix | string[16] | VideoClip1_ | 6/6 | Indicate the prefix of the filename. |
|
|
|
|
|
videoclip_preevent | 0 ~ 9 | 0 | 6/6 | Indicates the time for |
|
|
|
| recording in seconds. |
|
|
|
|
|
videoclip_maxduration | 1 ~ 20 | 5 | 6/6 | Maximum duration of one video clip in |
|
|
|
| seconds. |
|
|
|
|
|
videoclip_maxsize | 50 ~ 8192 | 3072 | 6/6 | Maximum size of one video clip file in |
|
|
|
| Kbytes. |
|
|
|
|
|
7.33 Recording
Group: recording_i<0~1>
PARAMETER |
| VALUE |
| DEFAULT |
| SECURITY |
| DESCRIPTION |
|
|
|
|
|
|
| (get/set) |
|
|
|
name |
| string[40] |
| NULL |
| 6/6 |
| Identification of this entry. |
|
|
|
|
|
|
|
|
|
|
|
trigger |
| schedule, |
| schedule |
| 6/6 |
| The event trigger type |
|
|
| networkfail |
|
|
|
|
| schedule: The event is triggered by |
|
|
|
|
|
|
|
|
| schedule |
|
|
|
|
|
|
|
|
| networkfail: The event is triggered |
|
|
|
|
|
|
|
|
| by the failure of network |
|
|
|
|
|
|
|
|
| connection. |
|
|
|
|
|
|
|
|
|
|
|
enable |
| 0, 1 |
| 0 |
| 6/6 |
| Enable or disable this recording. |
|
|
|
|
|
|
|
|
|
|
|
188 - User's Manual
