Setting Up (continued)

Connecting Power Supply

WARNING • Please use extra caution when connecting the power cord as incorrect or faulty connections may result in FIRE and/or ELECTRICAL SHOCK. Please adhere to the “User’s manual – Safety Guide” and the following.

•Only plug the power cord into outlets rated for use with the power cord’s specified voltage range.

•Only use the power cord that came with the projector. If it is damaged, contact your dealer to newly get correct one.

•Never modify the power cord. Never attempt to defeat the ground connection of the three-pronged plug.

•Make sure that you firmly connect the power cord to the projector and wall outlet.

1 Connect the connector of the power cord to the AC inlet of the projector. 1

2 Firmly plug the power cord’s plug into the outlet.

AC Inlet

Connector Side

Power cord

Image 11
