COMMAND CENTER Pages

Start > Start

This page allows you to verify the machine’s operating status. This will be the first screen that appears after COMMAND CENTER has been started up.

Item

Description





Select

Appears if COMMAND CENTER pages support multiple

Language

languages.



To change COMMAND CENTER language:



1. Open the Select Language drop down list by clicking it.



2. Select the appropriate language.



If you attempt to view COMMAND CENTER with a character



set other than the language that is used on the operation



panel’s display, some characters may be illegible.





Operation Panel

This indicates the machine’s operating status as displayed



on the operation panel. To update the display to the most



recent status, click the Refresh button.





Toner Level

This shows the approximate level of remaining toner. The closer



the value to 0%, the smaller the amount of remaining toner. If



you use non-original toner kit, the toner gauge measurement



will not be indicated correctly.





Network IP

Network IP information on the printing system is displayed.

Information

This allows you to verify the following information:



-

IP Address



-

IPv6 Address (Manual)



-

IPv6 Address (LinkLocal)



- IPv6 Addresses 1 to 5 (Stateless)



-

IPv6 Address (Stateful)



-

Host Name





System

System information on the printing system is displayed. This

Identification

allows you to verify the following information:



-

MAC Address



-

System Firmware



-

Engine Firmware



-

Panel Firmware



-

FAX Firmware



-

Serial Number



-

Asset Number.





Media Input

This shows paper size and media type for cassettes and MP tray.







Start > Status Pages

These pages allow you to verify the various settings (machine, printing, scanning, network and E-mail) that were made on the operation panel or using COMMAND CENTER.

It is divided by the following items.

-Network

-Device/Printer

-Scanner

-Device/Printer

-FAX / i-FAX

-Jobs

-Counters
