C H A P T E R 1

Product Overview

The Cisco SFS 7012™ is an industry leading modular system used for creating large, single-system Grid/Cluster server fabrics, or as a building block for larger fabrics. The SFS 7012 is designed to maximize performance, streamline operations, and ensure uptime by providing full hardware and software reliability, availability, and serviceability (RAS) features.

Leveraging InfiniBand (IB) — an industry-standard interconnect — the SFS 7012 provides high performance, offering a full bisectional bandwidth (FBB) fabric (10Gb-30Gb) and ultra-low switching latency. Additionally, the SFS 7012 can be configured to run at 2.5 Gbps single data rate (SDR), 5.0 Gbps double data rate (DDR), or both.

All major SFS 7012 components and expansion modules are field replaceable and hot pluggable. To allow easy scaling, the SFS 7012 provides 12 expansion slots. Each slot can support expansion modules with twelve 10 Gbit/sec (or 4X) IB ports, meaning the SFS 7012 can scale to 144 (4X) InfiniBand ports. The SFS 7000 Series switches make possible the highest density of InfiniBand fabrics available today.

SFS 7012 Feature Set

Strategic Benefits

Creates the industry’s simplest way to build medium to large server fabrics

Modular systems up to 144 ports (4X)

Eliminates requirement for parallel storage networks

High-availability design for mission critical needs

Lowers Total Cost of Ownership (TCO)

Key Design Features

All field-replaceable units (FRU’s) can be replaced while under power

Redundant management, power and cooling

High performance 10Gb/s

Full Bisectional Bandwidth InfiniBand switching fabric

Twelve (12) expansion slots for InfiniBand (4X)

SDR and DDR support

Embedded system management

Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide



OL-8787-04

1







Image 19
Contents Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide Page Preface Audience Connect Equipment to the Ports and Power On the System Snmp Configuring the Switch Default Gateway IP Address Capture Deprecated OL-8787-04 Initial release of the Cisco SFS New and Changed InformationViii Organization AudienceCisco.com ConventionsRelated Documentation Obtaining DocumentationCisco Product Security Overview Documentation FeedbackProduct Documentation DVD Ordering Documentation Product Alerts and Field Notices Reporting Security Problems in Cisco ProductsCisco Technical Support & Documentation Website Obtaining Technical AssistanceDefinitions of Service Request Severity Submitting a Service RequestObtaining Additional Publications and Information Page Xvi A P T E R SFS 7012 Feature SetKey Design Features Strategic BenefitsPower Design Features SFS 7012 Product SpecificationsMechanical/Thermal/Power Specifications Thermal Management FeaturesChassis Viewer Functionality Chassis Viewer SoftwareChapter Subnet Management Subnet ManagerSubnet Management Agents InfiniBand General Services Managers and Agents Snmp MIBs Snmp SupportOL-8787-04 Installation Statement 1019-Main Disconnecting Device Statement 1045-Short-circuit Protection Chapter Chapter Chapter Environmental Requirements Planning the InstallationInstalling and Routing Cable Rack Specifications and RecommendationsAssembly 90-Degree Bend Radii Power Supply Power RequirementsUninterruptible Power Supply Safety Information Installation Tasks ChecklistElectrical Safety Precautions Tools and Equipment Required Unpack the Equipment Check the Installation SiteMounting Kit Installation TasksInstall the Rails in the Rack Mounting Hardware Kit ContentsRail Front Flange Rack-Mount the Switch Installing the Switch Face Plate Removing a Module or Blank Installing the Spine and Leaf ModulesLeaf Connect Equipment to the Ports and Power On the SystemLeaf Start-up Procedures Connecting PowerBringing Up the System For the First Time Unmanaged Fan Managed System prompts for a password. At the prompt enter Reboot NEW IP Address Verifying Start-up SFS 7012 Component LEDsChassis Status LED SFS 7012 Leaf and Spine Module LEDs Spine and Leaf Module Attention LED Spine and Leaf Module Status LEDSpine Module Management LEDs 15 Chassis Viewer Online Help Buttons Accessing On-line HelpRebooting Components from Chassis Viewer Shutdown ProceduresRebooting Multiple Managed Spines Hot Swapping Spine and Leaf Modules Hot Swapping ComponentsHot Swapping the Fan Unit Hot Swapping Power SuppliesChassis Viewer Manages Chassis Viewer? Help Button HomeSupport Button Leaf Module View Displaying the Leaf and Spine Module ViewsSpine Module View Leaf and Spine Module Component Details AreaApply Leaf and Spine Details HeaderLeaf and Spine Information Area Displaying the Chassis ViewLeft click the mouse. The chassis view will be displayed Chassis Details Header Chassis View Component Details Area15 Reboot Screen LEDs and Sensors Tab Chassis View Component Information AreaChassis View Component Information Area Tabs System Information TabSystem Tab Chassis FRU Tab Power TabFan Tab Modifying Switch Component InformationBackplane Tab Chassis View Menu Configuration and Monitoring FeaturesLogging 20 Logging Submenu Set Level23 Device Tab Software Module Configurator 24 Log System Configurator Preset Tab Preset TabConfigure Syslog on a Linux Server Reset Log LevelsSyslog Tab 27 Reset Log Levels Window Firmware UpdateSelect Target Configuration Target ConfigurationSnmp Target Addresses Target Configuration Window Field DescriptionsSnmp Target Parameters 33 Filter Status Button Filter Status34 Filter Status Screen Setting Community Strings36 Set Community Strings Window Chassis TrapsIcsChassisTrapModuleReboot IcsChassisTrapSystemRebootIcsChassisTrapSystemSwitchFailover IcsChassisTrapModuleBulkPowerFailureIcsChassisTrapPowerSupplyEEPROMReadFailure IcsChassisTrapPowerSupplyInsertedIcsChassisTrapPowerSupplyRemoved IcsChassisTrapPowerSupplyFailedLeaf modules/ports Interswitch Link ISL PortsSFS 7012 Port Statistics Understanding Port Naming ConventionsInfiniBand Statistics Port Statistics Field DescriptionsRemote Physical Error Received Symbol ErrorsLink Error Recovery Receive ErrorsLeaf Modules Leaf and Spine Module IB Port StatisticsSpine Modules 44 Spine Port Statistics Window Set Field ThresholdsPortRecvPktsThresh PortXmitDataThreshPortRecvDataThresh PortXmitPktsThreshTime Service Click the Use Network Time Protocol? checkbox 47 Switch Time ServiceDaylight Saving Time Tips Time Zone TipsConfiguring the Switch Default Gateway IP Address Configuring the Switch OOB IP AddressFrom the OOB LAN IP submenu, click Set Default Gateway IP Type in the correct switch default gateway IP address Viewing the Log Spine View MenuSelect Edit, Copy or Ctrl + C Purging the LogSelect Edit, Paste or Ctrl + License Keys Key Administration Select Boot ImageDeleting a License Key Adding a New License KeyClick OK to delete Technical Specifications OL-8787-04 Overview AdministratorOperator Commands and Functional Groups Capture Accessing the CLIOnline Help Keyboard ShortcutsGeneral Groups and CommandsSmGetPriority DeprecatedSample Output ChassisNetwork Log FirmwareKeyManagement TimeManagement IbSwitchInfoCapture Hardware Checks SwitchPower Supply Problem FixSFS 7012 Leaf Module IB Ports OOB Ethernet RJ45 PortBad IB Cable Troubleshooting ScenariosInfiniBand Invalid IP Address entered for SWC via Console PortOL-8787-04
