SVS 100 Features

Four NTSC or PAL video inputs

2 S-video or composite video inputs — 2 rear panel, 4-pin mini-DIN connectors (Input 1 and Input 2) accept luminance (Y) and chrominance (C) input. Alternately, 2 rear panel BNC connectors accept composite video input. The video inputs can be specified through a menu system, as either Auto, Video, or S-video. Auto will automatically select the active input. If S-video and composite video are both input, the SVS 100 will automatically select the S-video input.

2 composite video only inputs — 2 rear panel BNC connectors (Input 3 and Input 4) accept composite video input.

Any inputs must either be all NTSC or all PAL, they cannot be both.

Four NTSC or PAL buffered output loops

2 S-video or composite buffered output loops — Input 1 and Input 2 each output a buffered loop of the selected video input on either 4-pinmini-DIN connectors (S-video) or BNC connectors (composite).

2 composite video only buffered output loops — Input 3 and Input 4 each output a buffered loop of the composite video input on BNC connectors.

Three NTSC or PAL video outputs

2 composite video outputs — Switched outputs on rear panel BNC connectors

1 S-video output — Switched output on rear panel 4-pin mini-DIN connector

Four balanced/unbalanced stereo audio inputs — Four rear panel captive screw terminals accept audio inputs. Each input’s level can be individually preset.

Pre-amp output for powered speakers is provided on a 3.5 mm, 5-pole captive screw terminal.

Seamless switching — Noise and other video glitches are eliminated by a user- selectable assortment of cut, wipe, dissolve, and fade effects.

Genlock connection — A black burst external sync signal can be input and daisy- chained via rear panel BNC connectors.

Picture controls — Color, tint, brightness, contrast, and top and bottom blanking can be adjusted for each input to correct for differences between sources.

Audio breakaway — Audio and video can be switched separately by using RS-232 control. This feature can be set through Extron’s Simple Instruction Set™ (SIS™).

RS-232/RS-422 control — A computer or other RS-232/RS-422 control device can be used to control the SVS 100 switcher with Extron’s Simple Instruction Set™ (SIS™) or the Windows-based control program.

Memory — 128 picture configurations can be stored in memory.

Versatile mounting options — The SVS 100 can be rack mounted, or it can be mounted under a desk or table, or against a wall or the side of a desk. Mounting brackets are included.
