Function Keys

F5 Edit:

For convenience in remembering which PC is attached to a particular port, every port can be named. The Edit function allows

you to name the currently highlighted CPU Port (if it doesn’t already have a name), or to modify/delete the Port Name if it does. To edit a Port Name:

1.Use the Navigation Keys to move the highlight bar to the port you want (you can use the F3 List function to broaden or narrow the port selection list).

2.Press [F5].

3.Add, modify or delete the Port Name. Legal characters include:

-All alpha characters: a-z; A-Z

-All numeric characters: 0-9

-+,-,/,:,., and Space

Case does not matter; OSD displays the Port Name in all capitals no matter how they were keyed in.

4.When you have finished editing, press [Enter] to have the change take effect. To abort the change, press [Esc].

31
