Remote Control (continued)

Using The Mouse/Keyboard Control Function

CAUTION • Before connecting, read the manuals of the device you will connect. Mistaken use of the mouse/keyboard control could damage your equipment.

Only connect to a PC.

Do not unplug the connector cables while the computer is operating.

Using the USB control feature, you can use the remote control as a simplified mouse or keyboard of the computer.

Connect the M1-D port of the projector to the computer via the M1-D cable. Then functions illustrated below will be enabled.

memo The USB control can be used with Windows 95 OSR 2.1 or higher. It may not be possible to use the remote control, depending on the computer’s configurations and mouse drivers.

memo The function can be used only for the functions illustrated on the right.

memo The projector would be enumerated as a mouse and a keyboard of HID (Human Interface Device) class devices, after connecting cable.

LASER INDICATOR

STANDBY/ON VIDEO RGB

+

+

+



LENS SHIFT

FOCUS

ZOOM

Mouse left button

BLANK

ASPECT

LASER



PREVIOUS



NEXT

Mouse move pointer



ENTER



ESC

MENU



Keyboard

POSITION

RESET

AUTO

Arrow keys / / /

MAGNFY

PinP

VOLUME



ON









FREEZE

MUTE

Mouse right button

OFF

KEYSTONE SEARCH



1 2 3



Keyboard ESC key

ID CHANGE



(Front)

(Rear)

14
