BOXLIGHT MP-58i, MP-57i user manual Option Menu

Multifunctional Settings (continued)

OPTION Menu (continued)

Item				Description
	Pressing the	(or the ENTER) button calls the SERVICE
									SERVICE
	menu.								FANSPEED		NORMAL
									AUTO ADJUST		ENABLE
	SERVICE Menu
									LENS TYPE		AUTO
	Select an item using the		/	buttons, and press the					LENS LOCK		TURN OFF
	(or the ENTER) button to per form each function. :								: SELECT
	FANSPEED	AUTO ADJUST			LENS TYPE	LENS LOCK
		Select the fan speed level using the					/	buttons. :
		HIGH	NORMAL
	FANSPEED	The HIGH ups rotation speeds of fans, though. Please use this
		function in using a projector at highlands etc.
		memo Note that the projector is noisier when the HIGH is
		selected.
		Select the ENABLE or the DISABLE using the							/
		buttons. :
		ENABLE		DISABLE
	AUTO	When you want to keep the current adjustment state, select
		the DISABLE. When the ENABLE is selected, detecting a
	ADJUST
		signal change to a RGB signal performs the automatic
SERVICE		adjustment of the vertical position (V POSITION), the horizontal
		position (H POSITION), the clock phase (H PHASE) and the
		horizontal size (H SIZE).
		Select the lens type currently used using the							/	buttons. :
		AUTO	1	2	3 4	5
		Please select depending on the following.
		AUTO: automatically selects optimum mode.
		1: for a standard lens (Type NL-500 etc.)
	LENS TYPE	2: for a fixed short throw lens (Type FL-501 etc.)
		3: for a short throw lens (Type SL-502 etc.)
		4: for a long throw lens (Type LL-503 etc.)
		5: for a super long throw lens (Type LL-504 etc.)
		memo This setting has an influence on the keystone distortion
		etc.
		memo About the optional lens, ask your dealer.
		Select the TURN ON or the TURN OFF using the								/
		buttons. :
	LENS LOCK	TURN ON		TURN OFF
		Selecting the TURN ON locks the adjustment of the lens shift,
		the zoom and the focus.

Select the EXECUTE using the button to reset the OPTION menu items. :

RESET

EXECUTE CANCEL

The items of the OPTION menu are collectively returned to the initial setting. Note that the items “VOLUME”, “LAMP TIME” and “FILTER TIME” are not reset.

34
