Page 43

Preparation:

•Turn ON the TV and set it to the video input mode.

•Make sure TV/VCR/DVD switch has been slided to VCR/DVD. Then press DVD to select the DVD mode. (The DVD indicator will light.)

JPEG CD playback

1 Press OPEN/CLOSE.

The disc tray will open.

Reading

Place a disc on which JPEG files

have been recorded onto the tray.

2 Press OPEN/CLOSE or PLAY.

The disc tray closes automatically.



On the TV-screen, “Reading” will



appear. Reading will take as much



time as the number of file.



3 A file menu screen will appear on the TV screen.

Press / to select folder.

4 Press / or / or Number keys to select the desired file.

CD-R









-/36









Collection







1



Pic-1

8

Pic-8

2



Pic-2

9

Pic-9

3



Pic-3

10

Pic-10

4



Pic-4

11

Pic-11

5



Pic-5

12

Pic-12

6



Pic-6

13

Pic-13

7



Pic-7

14

Pic-14

/0-9/Enter/Play Mode/Menu

CD-R







-/36





Collection













1









8







Pic-1

Pic-8

2





Pic-2

9

Pic-9

3





Pic-3

10

Pic-10

4





Pic-4

11

Pic-11

5





Pic-5

12

Pic-12

6





Pic-6

13

Pic-13

7





Pic-7

14

Pic-14

/0-9/Enter/Play Mode/Menu

About file menu







Operation









Elapsed time

Media type



File number



Folder









File type























































































































/Menu

: Indicates MP3 file

: Indicates WMA file

: Indicates JPEG file

NOTE:

The picture menu is displayed when the FUJICOLOR CD or the Kodak Picture CD are played. To display the file menu press TITLE.

To display a picture menu, press DVD MENU. (To return to a file menu, press TITLE.)

Press / or / to select the desired file.

• To display next list, press SKIP

/.

•When PLAY has been pressed after displaying the file menu, or when the disc tray has been closed after pressing PLAY in step 2, playback begins automatically starting from the first file. In this case, if the first file is a JPEG file, the first JPEG file is played back. If the first file is an MP3/WMA file, only MP3/WMA files are played back in order.

5 Press ENTER.

The selected picture appears on the TV screen.

6 Press STOP to end playback.

The file menu appears on the TV screen.

If you want to watch the other file, repeat steps 4-5.

43
