Philips VR 510/07 Sorting and clearing of TV channels manually, Channel to the programme

Page 15

MAIN MENU

CLOCK

AUTO INSTALL

MANUAL SEARCH

TV CHANNEL ALLOC.

RECORD SPEED

AUTO STANDBY

TV SYSTEM

SPECIAL SETTINGS

OK

TV

CHANNEL ALLOC.

ALLOCATE ON

QP01P

TV

CHANNEL

BBC1

ALLOCATEPSELECT STOREPOK

Sorting and clearing of TV channels manually

After you have performed the automatic channel search you may not agree with the sequence in which the individual TV channels have been allocated to the programme positions of the video recorder. You can use this function to individually sort the TV channels found or to delete unwanted TV channels or those with poor reception.

1Switch on the TV set and - if necessary - select the programme number set for video recorder operation

2Press the MENU button on the remote control.The on-screen menu appears

3Use =P- or ;P+ to select the option “TV CHANNEL ALLOC.” and confirm with OK

4Use S+ P or QS- to select the TV channel, to be allocated a programme position

5 Sorting:

Press SELECT, to allocate the TV



channel to the programme



position set P 01

Clearing:

Delete the TV channel set with



CLEAR (CL)

6Continue repeating the steps 4 and 5, to allocate additional TV channels (P 02, P 03,...) or to delete additional TV channels and confirm with OK

7Finish the manual sorting / clearing of TV channels with the button MENU

ENGLISH

15

SORTING AND CLEARING OF TV CHANNELS MANUALLY
