Philips VR 510/07 Manual recording, Starting and stopping of recording manually

Page 24

8Manual recording

n

P 0 1

v

Starting and stopping of recording manually

1Switch on the TV set and - if necessary - select the programme number set for video recorder operation

2Insert a cassette without erase protection

What is erase protection?



VHS cassettes can be protected from over-recording by



breaking off a thin strip of plastic (arrow). This erase



protection can be overridden by sticking one or more



strips of adhesive tape tightly over the gap which has

PARDON?

been created.

3Use the buttons =P- or ;P+ to select the programme number, under which your video recorder has stored the desired TV channel

8 I can’t find the TV channels from my satellite receiver

8 I want to record from an additional device





4 Signals from additional devices - such as a





camcorder, other video recorder, PCs, etc. - are





received via the scart socket of the video recorder.





The programme numbers “E1” and “E2” are

PROBLEM

allocated for these sources.













Selecting the recording speed





You have the option of two playback and recording





speeds: Standard Play (SP) offers the usual first-class





picture quality. By using Long Play (LP), you can (with





somewhat reduced picture quality) for example record





about 360 minutes of programmes on a 180 minute





cassette.This chapter explains how to set the desired





FOR

recording speed (“Selecting the recording speed”).

EXPERTS



4Start recording by pressing the Record button n (remote control or on front of set).The display will show “ ”.

Displaying tape position



With the OK button you can display the current tape

TIP

position (see chapter “Playback”)

5End the recording by pressing the Stop button h

STARTING / STOPPING RECORDING MANUALLY

24

ENGLISH
