Philips VR 510/07 Problem solving Turbo Timer programming, Error message CLK

Page 35

k

O K

6Insert a cassette without erase protection

What is erase protection?



VHS cassettes can be protected from over-recording by



breaking off a thin strip of plastic (arrow). This erase



protection can be overridden by sticking one or more



strips of adhesive tape tightly over the gap which has

PARDON?

been created.

7SWITCH OFF THE VIDEO RECORDER WITH THE STANDBY/ON BUTTON m ! IF YOU DONT DO THIS, THE SET WILL NOT RECORD.

The display will show “k”

Problem solving (Turbo Timer programming)

PROBLEMSOLUTION

Error message: “CASS”,

“k” will blink in the display

Error message: “FULL”

Cassette is ejected during recording

A recording was programmed, but there is no cassette in the machine. Insert a cassette ready for recording without erase protection.

All the available memory locations in your video recorder for timer and VIDEO Plus programming are full. Delete a programmed recording (see chapter “Delete / check / change programmed recordings”).

The end of the tape was reached during a programmed recording.The recording could not be completed satisfactorily.

Cassette is ejected after programming

The set cannot be used during recording

Error message: “CLK”

A cassette with erase protection was inserted. Please deactivate the erase protection or insert another cassette which is ready for recording.

Once started, a recording can only be interrupted by pressing the STANDBY/ON

button m.WARNING: This will not only stop the recording, but it will also delete the programmed recording from the memory of the video recorder.

The time has not been set or not set correctly. A Turbo Timer recording is not possible. Please enter the correct time (Section “Changing the time and date”)

ENGLISH

35

PROBLEM SOLVING
