User Guide
2. Component Name
User Guide
3. Function of Each Component
■Fixed focus lens
•Fixed focus lens installed on the camera. Please take cautions that any dust or foreign
Fixed focus lens
PCB board
Main body
Dome cover
Video cable
matter gathers on the front glass surface of the | E |
| |
lens. |
|
■ Main body |
• A body that supports the camera. |
■ PCB board |
• This part is quite important since it performs |
the camera function. Please handle with care. |
■ Power cable |
• The terminal that is connected to the power |
(adaptor) cable. Connect to DC 12V/AC 24V. |
Power cable
■ Video signal output cable |
• The cable that sends the video signal. |
■ Dome cover |
• The transparent plastic cover that protects the |
camera. |
Be careful not to make a scratch on it. |
4 |
|
|
| 5 |
|
| |||
|
|
|
|
|
