Cannon 5 ST, 10 STX TS owner manual 32 9100070 CON Leader Sleeve

Page 33

1902310 Magnum 10 STX TS

In the U.S.A., replacement parts may be ordered directly from CANNON Parts Dept., 121 Power Drive, Mankato, Minnesota 56001. Be sure to provide the MODEL and SERIAL numbers of your downrigger when ordering parts. Please use the correct part numbers from the parts list. Payment for any parts ordered from the CANNON parts department, may be by cash, personal check, Discover Card, MasterCard or VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.

www.cannondownriggers.com

13392525 FRAME, RAW, TS

22263102 NUT-HEX 1/4-20 SS 300SRS

33394722 INSERT, PUSH ON

43394702 INSERT, BASE

52372100 SCREW-#8-18 X 5/8 THD* (SS

63396510 LENS-WINDOW MAG DTIV

73395881 DECAL, MAG 10, TS

83396601 SEAL PLATE, MAGNUM

93391730 WASHER, SEAL, DATA

103398205 CIRCUIT BREAKER, 25 AMP

111221491 BOOT CIRCUIT BREAKER

123993220 ASSY, POWER CABLE, RETRO(SUB)

133392920 STRAIN-RELIEF, HEYCO M4502

143996515 MOTOR/GEAR HOUSING ASSY

153393411 SCREW-FLANGE HEX HI-LO

163394006 ASY PCA, MAGNUM

172302104 SCREW-#6-20 X 3/8

182286792 SWITCH, TOGGLE

193391722 WASHER, FLAT

202286793 HDW SHIM SWITCH .75X.1

211221490 BOOT SWITCH

223390204 COVER, MOTOR, TS

23401966-3 MIC VENT,PTFE LU LRA MATERIAL

243396902 GASKET, COVER

253393480 SCREW-#10X.75"PPH HI-LO SS

263391907 PLATE, CLUTCH SHAFT

273392640 PIN, DRIVESHAFT

283391711 PAD, CLUTCH

33

293397908 REEL, ROUGH, 3.75" OD

300233560 GEAR, REEL, STD

311015391 WIRE, .034 DIA, CAMO BULK

329100070 CON LEADER SLEEVE

333390206 COVER, REEL, TS

342373434 SCREW-1/4-20 X 3/4 SS PPMS

352071718 WASHER #10 NYLON RETAINING

363394605 O-RING, KNOB

370220477 METER 3 DIGIT

380833561 GEAR, COUNTER

393390103 KNOB, SOFT GRIP, CLUTCH

409010310 HDW WASHER, THRUST

419010280 HDW BEARING, THRUST

423395634 DECAL- SIDE, BLACK

433395711 DECAL-PIC BLACK, TS

442998905 CNN ASY, SWIVEL BASE

452249001 HDW KNB RELEASE PIN

463392600 PIN - RELEASE

472287002 HDW SPRING RELEASE PIN

482267001 ASY PLATE BASE MACHINED

492267002 BRK PLATE SWIVEL

503391919 PLATE, INDEX TS

512277001 HDW RETAINER RELEASE NUT

529010004 HDW BEARING SWIVEL BASE

533991930 ASY, MNT BASE DT/MAG(SUB)

543391955 BASE-MOUNT, DT PRO/MAG ST

553390101 KNOB-CANNON, SOFT GRIP

563393000 RING, RETAINING, 1/4" SHAFT

573991904 ASSY-CNN, ROD HOLDER

583394200 ARM, DUAL AXIS-ROD HOLDER

593392033 TUBE, DUAL AXIS RD HLDR

602200109 SALTWATER RELEASE

613392010 ASY BOOM TELESCOPIC, SS

623397900 BALL HOOK EXTRUSION

63 3990200 ASSY-CNN, BOOM END (SUB)

643392520 CASE, PULLEY

653392300 SHEEVE, PULLEY

663391507 SHIM, BOOM END

673392013 BOOM END, NEW

683393485 SCREW-#10-24X1.75 PPHMS S

693393124 NUT-#10-32 NYLOK 18-8 SS

702303412 SCREW-#6-20 X 5/8 SELF TAP

713390005 BEARING-NYLINER, #8L5-1/2-F

729280720 HDW SCR 1/4 20X2 TRUSS HD PHIL

739280713 HDW SCR 1/4 20X1 1/2 TRUSS HEA

742263103 NUT-1/4-20 NYLOCK SS

752371712 WASHER-FLAT 9/32 X 5/8 X 1/16

769100100 CON TERMINATOR

779100101 CUSHION SLEEVE TERMINATOR

789100620 HDW SNAP SWIVEL 4/0-37 MARLIN

792200148 ASY SNAP & INSULATOR

809040040 HDW BOLT 1/4-20 ROLLEDTHD HOOK

813393461 SCREW-1/4-20 x 2" SS, PPH

823390910 HANDLE-CRANK, MANUAL

833391732 WASHER, SEALING

843394602 WASHER, FLAT, #8, SS

List Parts
