Page 4

BEFORE YOU BEGIN

Congratulations for selecting the revolutionary PROFORM¨ L.E.X. low-impact elliptical crosstrainer. The L.E.X. is an incredibly smooth exerciser that moves your feet in a natural elliptical path, minimizing the impact to your knees and ankles. And the unique L.E.X. features adjustable resistance, dual-motion handlebars, and a multi-mode exercise monitor to help you get the most from your exercise. Welcome to a whole new world of natural, elliptical-motion exercise from PROFORM.

For your benefit, read this manual carefully before you use the PROFORM¨ L.E.X.. If you have ques-

tions after reading the manual, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is PFEL25070. The serial number can be found on a decal attached to the L.E.X. (see the front cover of this manual for the location of the decal).

Before reading further, please look at the drawing below and familiarize yourself with the parts that are labeled.

Water Bottle Holder

Handlebar

(Bottle is not included)





Console

Pedal



Resistance



Knob





Lock Pin

Handlebar



Resistance



Knob





FRONT

Side Shields



Stabilizer

Crank Arm

BACK

RIGHT SIDE

Pedal Arm

Pedal



4
