Hearth and Home Technologies 42, 36 owner manual Chimney Components, Catalog #

Page 34

C. Chimney Components

The following pictures show only those chimney components which may be safely used with this fireplace.

Catalog #



US

CAN

Description

CAK5A

CAK5A

Chimney Air Kit

n/a

SLA10

Adapter 11 in. (457mm) long

ID4

ID4

Insulated Duct/Outside Air

UD4

UD4

Uninsulated Duct/Outside Air

SL1106

SL406

Chimney Section - 6 in. (152 mm) long





Chimney Section - 12 in. (305

SL1112

SL412

mm) long





Chimney Section - 18 in. (457

SL1118

SL418

mm) long





Chimney Section - 36 in. (914

ID4 Insulated Duct

4 in. (102 mm) i.d.

42 in.

(1067 mm)

UD4 Uninsulated Duct

SL1136

SL436

mm) long





Chimney Section - 48 in. (1219

SL1148

SL448

mm) long

SL11

SL4

Chimney Stabilizer

SL1130

SL430

Chimney Offset/Return - 30 deg

FS538

FS538

Ceiling Firestop - Straight

FS540

FS540

Ceiling Firestop - 30 deg





Straight Attic Insulation Shield, 24 in.

AS10

AS10

(610 mm)

JB577

JB577

Chimney Joint Band

CB576

CB576

Chimney Bracket

RF570

RF570

Roof Flashing - Flat to 6/12 Pitch

RF571

RF571

Roof Flashing - 6/12 to 12/12 Pitch

42 in. (1067 mm)

4 in. (102 mm) i.d.

A

TR11

TR444

Round Termination Cap

TR11T

TR442

Round Telescoping Termination Cap

TCT1175



Terra Cotta Termination Cap

ST1175

ST475

Square Termination Cap

DTO134 DTO134

Short Octagon Decorative Cap

DTO146 DTO146

Tall Octagon Decorative Cap

DTS134 DTS134

Short Square Decorative Cap

DTS146 DTS146

Tall Square Decorative Cap

CT56

CT56

Chase Top





Decorative Shroud - 3 ft x 3 ft (.91

LDS33

LDS33

m x .91 m)





Decorative Shroud - 4 ft x 6 ft (1.22

LDS46

LDS46

m x 1.83 m)





Decorative Shroud - 26 in. x 26 in.

LDS-BV LDS-BV

(660 mm x 660 mm)





Field Constructed Shrouds (See





“Woodburning Termination Cap”)





Adapter-May be used with the following

CT-11A

n/a

Copper Caps



n/a

CT-Series



n/a

DT-Series

`

14 in.

14 in. (356 mm)

(356 mm)

5-1/4 in.



(133 mm)

4 in. (102 mm)

13 in.

(330 mm)

CAK5A Chimney Air Kit

18 in.

(457 mm)

11 in.

13 in.

(330 mm)

(279 mm)





B

Chimney Sections

Catalog #

A



B



US

CAN

in



mm

in



mm

SL1106

SL406

6



152

4-3/4



121

SL1112

SL412

12



305

10-3/4



273

















SL1118

SL418

18



457

16-3/4



425

SL1136

SL436

36



914

34-3/4



883

SL1148

SL448

48



1219

46-3/4



1187

A = Actual Length

B = Effective Length (length of

chimney part after it has

been snapped to another)

20-3/4 in.

Inside

Diameter

527 mm

11 in./279 mm SL11





10 in./254 mm SL4

Outside Diameter 13 in./330 mm

SL11/SL4 Chimney Stabilizer

SLA10 Adapter

34 Outdoor Lifestyles by Hearth & Home Technologies Inc. • Montana US-CAN4039-156 Rev K 7/11
