Braun 32899 Rev A manual Third Row Power Seat Operation, To Fold and Return Seat Back, Lvuhjdug

Page 42

SEAT REMOVAL AND INSTALLATION

Third Row Power Seat Operation

7KLUGURZIROGLQJSRZHUVHDWVKDYHEHHQPRGLÀHGGXU- ing Rampvan conversion procedures. The seat back automatic fold/return feature has not been affected by WKHPRGLÀFDWLRQV)ROGDQGUHWXUQWKHVHDWEDFNDV outlined below and detailed in the Toyota OEM owner’s manual. The seat stow feature has been GLVDEOHG. The rear seat must be removed to utilize the full rear cargo area. Remove and install the seat as detailed.

)ROGLQJDQG5HWXUQLQJ7KLUG5RZ3RZHU6HDW

The seat FOLDING/RETURNING switches are located in the upper hatch opening (header interior panel). Use this switch to automatically fold and return the seat back.

6HDW%DFN$QJOH Use the control switch located at the front outboard corner of the seat base to adjust the seat back angle.

7R)ROG6HDW%DFN Push the overhead FOLDING/ RETURNING switch to fold the seat down.

7R5HWXUQ6HDW%DFN Push the overhead FOLDING/ RETURNING switch to return the seat to the original position (vertical).

To Fold and Return Seat Back:

Press and UHOHDVH this switch.

Seat Stow Feature is Disabled:

'LVUHJDUG

this switch.
