Panasonic KX-TG2421AL General use, Programmable settings, Problem Cause & solution

Page 41

TG2421AL_2422AL(e).book Page 41 Tuesday, March 15, 2005 6:29 PM



Useful Information









Troubleshooting







General use







Problem

Cause & solution

The unit does not work.

LMake sure that the battery is installed correctly (page



10).



LCheck the connections (page 9).



LFully charge the battery (page 11).



LClean the charge contacts and charge again (page 11).



LUnplug the base unit’s AC adaptor to reset the unit.



Reconnect the adaptor and try again.



LRe-install the battery (page 10) and fully charge it.





The display shows “No

LThe handset is too far from the base unit. Move closer

link to base. Move

and try again.

closer to base, try

LPlug in the base unit’s AC adaptor.

again.” and an alarm

LRaise the base unit antenna.

tone sounds.

LIf the above remedies do not solve the problem, the



handset may have lost communication with the base



unit. Register the handset again (page 34).





I cannot hear a dial tone.

LConfirm that the telephone line cord is connected (page



9).



LDisconnect the unit from the telephone line and connect



a known working telephone. If the working telephone



operates properly, contact our service personnel to



have the unit repaired. If the working telephone does



not operate properly, contact your telephone company.









Programmable settings





Problem

Cause & solution

I cannot programme

LProgramming is not possible while the handset and

items.

base unit are being used.



LDo not pause for over 1 minute while programming.



LMove closer to the base unit.

While programming, the

LA call is being received. Answer the call and start again

handset starts to ring.

from the beginning after hanging up.





41
