HP 620n Fast Ethernet Print Server manual Port Select, On Autonegotiation is enabled, or

Page 23

Note

The HP Jetdirect 10/100Base-TX print server may



require up to 10 seconds to establish a connection



on the network.

Try the following troubleshooting procedures:

Verify cabling connections.

Configure the print server’s 10/100TX link setting directly (for example, using the EIO menu on the printer’s control panel). Verify that the configuration of the connecting network device (such as a network switch) matches. For example, if you set the print server for 100Base-TX Full-Duplex operation, the port on the network switch must also be set to 100Base-TX Full-Duplex operation. Power-cycle the printer to reinitialize the setting.

On the Jetdirect Configuration Page, compare your configuration for the following parameters:

Parameter

Expected Messages for 10/100TX Cards





PORT SELECT:

RJ-45





PORT CONFIG:

100TX HALF, 100TX FULL, 10BASE-T HALF,



10BASE-T FULL





AUTONEGOTIATION:

ON (Autonegotiation is enabled), or



OFF (Autonegotiation is disabled, 10/100TX



configuration has been manually set)





ENWW

Troubleshooting Tools 23
