D9412GV2/D7412GV2 Operation and Installation Guide 9.0

Off-Board Points



















































































































Figure 14: Program Record Sheet



































































































































D9412GV2/D7412GV2 Program Record Sheet RADXPNTS Handler









EN 25















Default values are shown in ( ) or in bold





































Point Assignments (001 through

040)

















































































POPIT Switch



Trans-

Point

Point



Area

Debounce



BFSK/





Custom Point Text













Setting



lation

#

Index



Assign



Relay























































100

001

(3)

_ _



(1)

___

(2)

_____



(1)

____

P1 FIRE

___________________

















200

002

(1)

_ _



(1)

___

(2)

_____



(2)

____

P2

PANIC

___________________



















300

003

(25)

_ _



(1)

___

(2)

_____



(3)

____

P3

DELAY

___________________



















400

004

(13)

_ _



(1)

___

(2)

_____



(4)

____

P4

FOLLOW ___________________

















500

005

(7)

_ _



(1)

___

(2)

_____



(5)

____

P5

INSTANT ___________________

















600

006

(7)

_ _



(1)

___

(2)

_____



(6)

____

P6

INSTANT ___________________

















700

007

(7)

_ _



(1)

___

(2)

_____



(7)

____

P7

INSTANT ___________________

















800

008

(7)

_ _



(1)

___

(2)

_____



(8)

____

P8

INSTANT ___________________









0 1 2 3 4 5

6

101

009

__ __



(1)

___

(2)

_____



(1)

____

P9





___________________

























































9.3.8POPIT Labels

D9412GV2 off-board points are numbered 9 to 127 and 129 to 247. The D7412GV2 uses Points 9 to 75 only. The D9412GV2 reserves Points 128 and 248 for internal use. POPITs must be connected for Points 129 to 247 to expansion loops connected to POPEX #2.

Two sheets of peel-off POPIT labels are supplied with the D8125 POPEX Module. Use the sheet marked “Bank1” for Points 9 to 127. Use the sheet marked “Bank2” for Points 129 to 247.

Each label has two parts. Place the smaller part (with only the point number) on the chip. Place the larger part (with the switch settings) on the base of the POPIT. Set the switches and cover the POPIT.

Do not program two POPITs for the same point number. After programming all the points, perform a Service Walk Test. The D9412GV2/D7412GV2/ D7212GV2 Installation and Troubleshooting Quick Reference Guide (P/N: F01U003638) contains instructions for performing a Service Walk Test. If a point does not test, check the programming for a duplicated address.

Walk Test and Service Walk Test Do Not Show Extra Points: If the point assignment switches on a POPIT or OctoPOPIT are set incorrectly, it can create both missing and extra points. If the same point number is assigned to two or more POPITs or OctoPOPITs, none of the points with that number test correctly. Refer to Section 9.1 Point (Zonex) Bus: D9412GV2 Terminals and D7412GV2 Terminals on page 34.

9.4

D8128D OctoPOPIT Module



Modules D8128, D8128A, or D8128B are



incompatible with the D9412GV2 or



D7412GV2. Use only the D8128D



OctoPOPIT Module. Using Modules D8128,



D8128A, or D8128B can cause intermittent



Missing and Restoral Reports.

9.4.1

Description

The D8128D OctoPOPIT Module combines the functions of the D8125 POPEX Module and the D8127/D9127 POPIT Modules to provide eight off- board points in a single module. You can wire both D8128D OctoPOPIT and D8125 POPEX Modules in parallel to the Zonex Bus terminals on the same control panel.

Review Section 6.0 Power Outputs on page 25 to ensure there is enough power for the OctoPOPITs and other powered devices that will be connected to the system.

Up to thirty D8128D Modules can be connected to the D9412GV2 Control Panel. A maximum of nine D8128Ds can be connected to the D7412GV2 Control Panel (three points can be used on the last OctoPOPIT).

9.4.2Listings

The D8128D OctoPOPIT Module is UL Listed for Local or Police Connected Burglary Alarm, Central Station Burglary Alarm, Household Burglary Alarm applications, and commercial fire applications (UL 864 and NFPA 72).

40

Bosch Security Systems, Inc. 5/05 F01U003641B
