DeLonghi ESAM4400 Press OK to select English, English selected, Fill Tank, Turn the Steam Knob

Page 10

3 INSTALLATION

•After removing the packaging, make sure the product is complete and undamaged. If in doubt, do not use the appliance and contact a qualified professional.

•Packing elements (plastic bags, polystyrene etc) must not be left within reach of children as they may represent a hazard.

•Place the appliance on a work surface far away from water taps, basins and sources of heat.

•After positioning the appliance on the work top, leave a space of at least 2 in (5 cm) between the surfa- ces of the appliance and the side and rear walls and at least 8 in (20 cm) above the coffee maker.

•Never install the appliance in environments where the temperature may reach freezing or below freezing temperatures (the appliance could be damaged if the water freezes).

•Connect the appliance to a grounded socket with a minimum current rating of 10amps. The manufactu- rer is not liable for possible accidents caused by failure to do so.

•If the power socket does not match the plug on the appliance, have the socket replaced with a suitable type by a qualified professional.

•The power cable on this appliance must not be replaced by the user as this operation requires the use of special tools. If the cable is damaged or requires replacing, contact an authorized service center only to avoid all risks.

•You should personalize water hardness as soon as possible following the instructions in section 12.6.

To learn how to operate the appliance correctly, when you use it for the first time, follow the step-by-step instructions given in the following sections.

4 USING FOR THE FIRST TIME

1.The first time you use the appliance, select the language.

To set English, plug the appliance into the outlet and wait for the appliance to display:

PRESS OK TO select ENGLISH

Press the

button for at least 3 seconds until the appliance displays:

ENGLISH selected

The appliance then displays the setting message in English.

2. After a few seconds, the appliance displays:

FILL TANK

To fill, remove the tank (fig. 1), rinse and fill with fresh water. Never exceed the MAX line.

(When removing the tank, the cappuccino frother must always be positioned towards the center of the appliance, otherwise the tank cannot be removed).

Put the tank back and push as far as it will go.

3. The appliance now displays:

TURN the STEAM KNOB

9

Page 9 Page 11
Image 10
Page 9 Page 11
Contents Fiducia Italiana S.A DE C.V Uniti e Canada Caratteristiche Elettriche 120V˜60HZ 1350WPage Page Page Page Index Important Safeguards Description see Safety WarningsCoffee spout adjustable in height Control panel Menu Bean container lidFill Tank Press OK to select EnglishEnglish selected Turn the Steam KnobHeating UP Please Wait Preparing Coffee Using Coffee BeansTurning OFF Please Wait Rinsing Completed Please WaitEmpty Grounds Container Regulating the Coffee Mill Changing the Quantity of Coffee in the CUPButton is pressed Ready HOT Water Ready PRE-GROUNDProducing HOT Water Cleaning and Maintenance Preparing Cappuccinos Using SteamSteam Snapped out Until it clicks into placeAfter having heard the click Bottom pipe on the infuserStart Time Changing and Setting the Menu ParametersClock Correct IncorrectDescale no AUTO-START noDescale Descaling Completed Turn KnobTEMP. Warm RinsingRinsing Completed Turn Knob OFF After 1 HourContainer Reset to Default noTroubleshooting Changing the LanguageGenerica alarm Problem Cause Solution Ver the coffee Ground coffee is beingDoor Limited Warranty Table DES Matières Mesures DE Securite Importantes Description DE L’APPAREIL Voir Lisez Attentivement CE Mode D’EMPLOI ET CONSERVEZ-LEConsignes DE Sécurité Français Programmé Première Mise EN ServiceAppuyer SUR OK Pour Programmer Français Remplir LE RéservoirRinçage terminé Veuillez Patienter Arrêt EN Cours Veuillez PatienterChauffage Veuillez Patienter Machine Prête forteVider LE Tiroir À Marc Modification DE LA Quantité DE Café EN Tasse Réglage DU Moulin À CaféMachine Prête EAU Chaude Machine Prête PrémouluSortie D’EAU Chaude 10 Préparation DU Cappuccino Avec LA Vapeur VapeurNettoyage ET Entretien Rieur de l’infuseur Tube inférieur de l’infuseurSupport Axe ’axe doit être introduit dans le tube inféOuinon HorlogeMarche Modification ET Programmation DES Paramètres DU MenuDétartrage NON Automatique NONDÉTARTrer Détartrage OUITempérature Moyenne RinçageRinçage Terminé Tourner LE Bouton Arrêt Après 1 HeureModification DE LA Langue Dureté EAUPROGRAM. Usine NON Signification DU Message Affiché ET QUE FaireGrains Introduire LA MoutureProblèm Cause Solution Problèmes Solubles Avant D’APPELER L’ASSISTANCE TechniqueAu lieu de sortir par les Fait pas de caféBuses, le café coule le Page Índice Conserve Estas Instrucciones Piloto Menú Descripción DEL Aparato Véase LA PÁGAdvertencias DE Seguridad ¡LEA Detenidamente Y Guarde Estas InstruccionesLlenar Depósito Pulsar OK Para Instalar EspañolEspañol Instalado Girar VaporEnjuague completo SE Ruega Esperar Apagado EN SE Ruega EsperarCalentamiento SE Ruega Esperar Lista Para EL USO Sabor fuerteVaciar Cajón Posos Modificar LA Cantidad DE Café EN LA Taza Regulación DEL Molinillo DE CaféLista Para EL USO Agua Caliente Lista Para EL USO PremolidoErogación DE Agua Caliente Vapor Preparación DEL Capuchino Utilizando VaporLimpieza Y Mantenimiento Auto on Modificar Y Configurar LOS Parámetros DEL MenúReloj Correcto IncorrectoDescalcificación no Autoencendido noDescalcificación Descalcificación SÍTemperatura Media EnjuagueEnjuague Completo Girar Mando OFF Después DE 1 HSignificado DEL Mensaje Visualizado Y QUÉ Hacer Valores Fábrica noModificar LA Lengua Mensaje Significado QUÉ HacerPulsar NEXT+ Change Problema Causa Solución Por la cafetera Se ha utilizado el caféPremolido en lugar de El café no sale por lasDuración de la garantía Exclusiones de la garantíaCafetera Electrica Modelo ESAM4400 GarantiaPara Mexico solamente Fecha DE CompraIndice Avvertenze Importanti Spia Menu Descrizione DELL’APPARECCHIO Vedere PAGAvvertenze DI Sicurezza Leggere Attentamente E Conservare Queste IstruzioniRiempire serbatoio Premere OK per installare italianoItaliano installato Ruotare manopola vaporeRisciacquo completo attendere prego Spegnimento in corso attendere pregoRiscaldamento ATTENDERe Prego Pronta all’uso gusto normaleSvuotare Contenitore Fondi Nota 3 Consigli per ottenere il caffè più caldoModifica Della Quantità DI Caffè in Tazza Regolazione DEL MacinacaffèPronta All’uso acqua calda Pronta alL’USO PRE-MACINATOErogazione DI Acqua Calda Preparazione DEL Cappuccino Utilizzando IL Vapore VaporePulizia E Manutenzione Dopo aver sentito il click di Push fino a sentire il clic diAggancio SternoCorretto Errato OrologioAccensione Modifica E Impostazione DEI Parametri DEL MENU’Decalcificazione no Autoaccensione noDecalcificare Decalcificazione SISpegni Dopo 1 ORA RisciacquoRisciacquo COMPLETo Ruotare Manopola Parametri Programmazione della durezza dell’acquaValori Fabbrica no Premere OK PER Installare ItalianoDurezza Acqua Ruotare manopolaInserire gruppo Infusore Problemi Risolvibili Prima DI Chiamare Lassistenza Tecnica Problema Causa RimedioNa non eroga il caffè Si è utilizzato il caffèPremacinato al posto Vizio

ESAM4400 specifications

The DeLonghi ESAM4400 is a remarkable fully automatic espresso machine that has gained popularity among coffee enthusiasts for its versatility and performance. This device combines elegance with functionality, making it a perfect addition to any kitchen or coffee bar.

One of the standout features of the ESAM4400 is its integrated burr grinder, which ensures that coffee beans are ground fresh for each cup. This technology enhances the flavor and aroma of the coffee while allowing users to adjust the grind size to match their personal preferences. The machine also features a convenient bean container that can hold up to 200 grams of coffee beans, reducing the frequency of refills.

The ESAM4400 showcases an intuitive control panel with an easy-to-read display. Users can effortlessly select their desired coffee strength, cup size, and temperature, while the programmable settings allow for customized brewing options. This machine accommodates a variety of drinks, from espresso to cappuccino, allowing users to enjoy barista-quality beverages at home.

Another notable characteristic of the ESAM4400 is its advanced milk frother, which incorporates a unique cappuccino system. This system is designed to automatically combine steam and milk, creating rich, creamy froth that elevates any coffee experience. The adjustable milk frother allows users to customize the milk texture for different beverages, making it suitable for lattes, macchiatos, and more.

The DeLonghi ESAM4400 also stands out in terms of ease of maintenance. The removable brewing unit and drip tray make cleaning simple, while the auto-rinse feature ensures that the machine is always ready for use. It also includes a water filter that helps maintain the quality of each brew and prolongs the lifespan of the machine.

In terms of design, the ESAM4400 boasts a sleek and modern aesthetic, making it a stylish addition to any countertop. Its compact size makes it suitable for kitchens with limited space, while the stainless steel accents provide a touch of elegance.

Overall, the DeLonghi ESAM4400 offers a comprehensive solution for coffee lovers seeking convenience without sacrificing quality. With its range of features, advanced technologies, and user-friendly design, this espresso machine is capable of delivering café-style beverages right at home, ensuring a satisfying coffee experience every time. Whether you are a casual drinker or a dedicated aficionado, the ESAM4400 is a reliable companion for all your coffee needs.
