Filter Cleaning

2002 Dimension One Spas Export Owner’s Manual

Routine Equipment Maintenance

Draining Your Equipment

Risk of Accidental Drowning. Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use this system unless they are supervised at all times.

Danger

All models are gravity drained. Do not drain water onto your lawn or plants unless all of the bromine or chlorine has dissipated from the water. The sanitizer in your water will dissipate quickly by leaving the cover off and exposing the water to direct sunlight. Drain and replace your water every six months. For heavy water use, you may wish to change the water more frequently.

You may purchase an optional submersible pump from your dealer or from our Virtual Showroom at www.d1spas.com to provide quicker drainage.

Feature

Before cleaning the filter element(s) place the spa in the “Standby” mode by pressing the Dimension One Spas ICON logo for 5 seconds. Your system is equipped with one or two top access filter cartridges. We recommend that you clean the filters every month as preventative maintenance.

To clean the skimmer filter cartridge, remove the access lid covering the filter area. Lift the center float of the skimmer assembly until it is fully extended. Hold the centerpiece of the assembly and turn it counterclockwise until the flats of the basket are aligned with the securing tabs. Then pulls the basket assembly straight up to remove. Next, remove the E-Z Lock Filter cartridge by twisting the cartridge 1/4 turn counterclockwise to its stop. (Be careful not to overturn the filter) Then lift the filter out of its canister. Clean the cartridge with a high-pressure garden hose. Every other cleaning, soak the cartridges in a filter-cleaning solution, rinse it thoroughly, and reinstall. Replace the skimmer basket assembly and the access lid or cover. Exit the “Standby” mode by pressing Dimension Spas ICON logo for 5 seconds. After cleaning, run the pump for a few minutes at high speed, then return to the heating mode.

To clean the Ultra Pure™ filter cartridge for those hot tubs with Ultra Pure, remove the access lid and remove the E-Z Lock Filter cartridge by twisting the cartridge ¼ turn counterclockwise to its stop. Then lift the filter out of its canister. Clean the cartridge with a high-pressure garden hose. Every other cleaning, soak the cartridge in Dimension One Spas’ Cartridge Cleaner, then rinse it thoroughly, and reinstall. Replace the access lid or cover. Exit the “Standby” mode by pressing Dimension Spas ICON logo for 5 seconds.

Light Bulb Replacement

All systems are equipped with a 12 volt light using a GE912 bulb. To change the bulb:

1.Turn the power off and drain the system below the level of the light.

2.Using the special tool provided in the owner’s manual packet, unscrew the cover for the light housing.

3.Remove the old bulb and install the new bulb.

4.Use the special tool to replace the cover for the light housing.

5.Check to ensure proper operation of the new bulb before refilling the system.
