Exmark 920 manual Troubleshooting

Page 50

Troubleshooting

Problem



Possible Cause



Corrective Action











Engine loses power

1.

Engine load is excessive

1.

Reduce the ground speed.



2.

Air cleaner is dirty.

2.

Clean or replace the air cleaner element.



3.

Oil level in the crankcase is low.

3.

Add oil to the crankcase.



4.

Cooling fins and air passages for the

4.

Remove the obstructions from the cooling





engine are plugged.



fins and air passages.



5.

Vent hole in the fuel cap is plugged.

5.

Clean or replace the fuel cap.



6.

Dirt in fuel filter.

6.

Replace the fuel filter.



7.

Dirt, water, or stale fuel is in the fuel

7.

Contact an Authorized Service Dealer.





system.















Engine overheats.

1.

Engine load is excessive.

1.

Reduce the ground speed.



2.

Oil level in the crankcase is low.

2.

Add oil to the crankcase.



3.

Dirty air filter.

3.

Clean or replace the air cleaner element.



4.

Coolant level is low.

4.

Add coolant.



5.

Debris on or around radiator.

5.

Remove debris (see Clean the Radiator









section in Maintenance).



6.

Water pump or alternator belt is worn,

6.

Contact an Authorized Service Dealer.





loose, or broken.















Mower pulls left or right (with levers fully

1.

Tracking needs adjustment.

1.

Adjust the tracking.

forward)

2.

Tire pressure in drive tires not correct.

2.

Adjust tire pressure in the drive tires.





3.

Reverse indicator and motion control

3.

Adjust the reverse indicator and the





linkage need adjustment.



motion control linkage.











Machine does not drive

1.

By pass valve is not closed tight.

1.

Tighten the by pass valve.



2.

Drive or pump belt is worn, loose or

2.

Change the belt.





broken.







3.

Drive or pump belt is off a pulley.

3.

Change the belt.



4.

Broken or missing idler spring.

4.

Replace the spring.



5.

Hydraulic fluid level is low or too hot.

5.

Add hydraulic fluid to reservoir or let it









cool down.











Uneven cutting height.

1.

Blade(s) not sharp.

1.

Sharpen the blade(s).



2.

Cutting blade(s) is/are bent.

2.

Install new cutting blade(s).



3.

Mower deck is not level.

3.

Level mower deck from side-to-side and









front-to-rear.



4.

Underside of mower is dirty.

4.

Clean the underside of the mower.



5.

Tire pressure in drive tires not correct.

5.

Adjust tire pressure in the drive tires.



6.

Blade spindle bent.

6.

Contact an Authorized Service Dealer.



7.

Tips of adjacent blades are at an uneven

7.

Replace blades, spindles and (or) check





cutting height. Blades tips should be even



for damage to mower deck.





within 3/16 inch which is approximately









one blade thickness.















Abnormal vibration

1.

Cutting blade(s) is/are bent or unbalanced.

1.

Install new cutting blade(s).



2.

Blade mounting bolt is loose.

2.

Tighten the blade mounting bolt.



3.

Engine mounting bolts are loose.

3.

Tighten the engine mounting bolts.



4.

Loose engine pulley, idler pulley, or blade

4.

Tighten the appropriate pulley.





pulley.







5.

Engine pulley is damaged.

5.

Contact an Authorized Service Dealer.



6.

Blade spindle is bent.

6.

Contact an Authorized Service Dealer.



7.

Belt is damaged.

7.

Install new belt.











50

Page 49 Page 51
Image 50
