Port 80 Code	Driver Name	Port 80 Code	Driver Name

C0	SmmAccess	7F	Font (French)
46	PciHostBridge	8D	Font (Chinese)

47	PciExpress	B1	UnicodeCollation

CD	GmchMbi	5A	ConPlatform

48	IchInit	5D	ConSplitter

49	IdeController	79	GraphicsConsole

4A	SataController	7A	Terminal

4B	IchSmbusLight	5E	VgaClass

C1	SmmControl	5B	SaveMemoryConfig

C8	Ich7MSmmDispatcher	5C	AcpiSupport

4C	IsaAcpiDriver	53	AcpiPlatform

52	Fwh	5F	DataHub

CE	SmmFwh	7B	DataHubStdErr

54	PciHotPlug	61	GenericMemoryTest

51	BootOptionPolicy	60	DiskIo

76	SetupUtility	7C	Fat

55	Platform	7D	Partition

56	PlatformIde	6B	PciPlatform

D9	Ppm	45	AlertStandardForma

CC	Platform	A8	PciSerial

D0	Ihisi	A7	AsfInit

f9	SetupMouse	A9	IdeRController

D1	Int15Microcode	63	Legacy8259

D2	SmmPnp	64	LegacyRegion

57	Smbios	65	LegacyInterrupt

58	MemorySubClass	66	BiosKeyboard

59	MiscSubclassDriver	67	BiosVideo

AB	SysPassword	68	MonitorKey

AC	PswdConsole	69	LegacyBios

D7	HddPswdServiceBody	6A	LegacyBiosPlatform

A6	HddPswdService	77	LegacyMouse

80	HiiDatabase	78	SmmUsbLegacy

82	OemSetupBrowser	AA	AmtbxInvoke

7E	Font(English)	83	OemBadgingSupport

Code	Beeps	POST Routine Description

02h		Verify Real Mode
03h		Disable Non-Maskable Interrupt (NMI)

04h		Get CPU type

06h		Initialize system hardware

08h		Initialize chipset with initial POST values

09h		Set IN POST flag

152

Chapter 4

Image 162

Acer 5940G manual Code Beeps Post Routine Description
