Page 152

7-pin mini-DIN connector (optional adapter

PC Card (continued)

Cards supported	3.3 V and 5 V PC Cards
	1.5 V ExpressCards (with adapter)
PC Card connector size	68 pins
Data width (maximum)	PCMCIA 16 bits
	CardBus 32 bits

Memory

Memory module connector	two user-accessible SODIMM sockets
Memory module capacities	512 MB, 1 GB, and 2 GB
Memory type	GM 965 supports 533 MHz and 667 Mhz
	DDR2
	GL 960 supports 533 MHz DDR2
Minimum memory	512 MB
Maximum memory	GM 965 supports 4 GB
	GL 960 supports 2 GB

Ports and Connectors

Serial	9-pin connector; 16550C-compatible,
	16-byte buffer connector
Video	15-hole connector
Audio	microphone miniconnector, stereo
	headphones/speakers miniconnector
S-video TV-out	7-pin mini-DIN connector (optional adapter
	cable(s) with S-video and composite video
	connectors)
USB	four 4-pin USB 2.0-compliant connectors
Infrared sensor	sensor compatible with IrDA Standard 1.1
	(Fast IR) and IrDA Standard 1.0 (Slow IR)
Modem	RJ-11 support
IEEE 1394a	4-pin serial connector
Mini-Card	one Type IIIA Mini-Card slot

152

Specifications

Image 152
