Samsung NX1 Size and Resolution

Shooting Functions

8989

S

h

ooting Function

s

Shooting Functions

Photo size

As you increase the resolution, your photo or video will include more

pixels, so it can be printed on larger paper or displayed on a larger screen.

When you use a high resolution, the le size will also increase. Select a low

resolution for photos that will be displayed in a digital picture frame or

uploaded to the web.

To set the size,

In Shooting mode, press [m]

ĺ

b

ĺ

Photo Size

ĺ

an option.

* Default

Icon Size Recommended for

(3:2) 6480X4320* Printing on A0 paper.

(3:2) 4560X3040 Printing on A2 paper.

(3:2) 3264X2176 Printing on A3 paper.

(3:2) 2112X1408 Printing on A5 paper.

(16:9) 6480X3648 Printing on A0 paper or viewing on an

HDTV.

(16:9) 4608X2592 Printing on A2 paper or viewing on an

HDTV.

(16:9) 3328X1872 Printing on A4 paper or viewing on an

HDTV.

(16:9) 2048X1152 Printing on A5 paper or viewing on an

HDTV.

(1:1) 4320X4320 Printing a square photo on A2 paper.

(1:1) 3088X3088 Printing a square photo on A3 paper.

(1:1) 2160X2160 Printing a square photo on A4 paper.

(1:1) 1408X1408 Printing a square photo on A5 paper.

Available options may dier depending on shooting conditions.
