Page 29

3.Connect the other end to an appropriate power outlet.

4.Press the power switch to the "I" position to turn on your IMAGE SCANNER IS100e. After showing the warming up message, the LCD display prompts the Copy ready status (present) as shown below.

Note: You can leave your IMAGE SCANNER IS100e ON at all times since IMAGE

SCANNER IS100e is designed with a power saving function. If IMAGE SCANNER IS100e is idle for four hours, it automatically shuts off the scanning lamp. Press any key to return from the power saving function.

Setting up Your Machine 2-7
