Lanier IS100e manual Settings on the Server, Ftp, Http and Avpp

5 Managing Filing Folders

Settings on the Server

FTP

FTP uses RFC 959[FTP] as its protocol. Therefore, please make sure you have legal FTP account with the privilege of writing under the directory to save the files and the password before using FTP to save the files. To add a sub-directory from IMAGE SCANNER IS100e, you need to have the privilege of adding a new directory. When setting <NEW FOLDER> in IMAGE SCANNER IS100e, fill the account and password in the field of Server UID and Password respectively.

HTTP and AVPP

Both HTTP and AVPP use RFC 2616[HTTP 1.1] as their protocol. If you are not using the HTTP port or AVPP port 80 to save the files, you must change the HTTP Port or AVPP Port of IMAGE SCANNER IS100e to the port for the Web Server.

Generally speaking, Web Server, such as IIS or the other HTTP server, will use anonymous account for authentication, so that the user can link directly to the web page without entering the user name and password first. Hence, if the HTTP or AVPP Server allows anonymous account for authentication when you use IMAGE SCANNER IS100e to keep the files, there is no need for setting any text in the field of ServerID and Password of IMAGE SCANNER IS100e.

Managing Filing Folders 5-1
