Page 10

About This Manual

Power Supply Safety Markings

Alternating Current	Off (Supply)
Earth (Ground) Terminal	Caution (Hot Surface)
Protective Conductor Terminal	Caution	(Check	manual	for
	additional information.)

On (Supply)

viii	Operating Manual for XFR 2.8kW Series Power Supply
