C H A P T E R 1

Installation

This chapter describes how to install the Cisco SFS 7012™ and its components, and it includes the following information:

•Planning the Installation, page 1-7

•Installation Tasks, page 1-12

•Hot Swapping Components, page 1-30

Note Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information for the Cisco Server Fabric Switches: 7000P, 7000D, 7008P, 7012, 7024, and 3012R for important safety information.

Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide

	OL-8787-05	1-1
