2

Network Requirements

Before installing the 2H253-25R, review the requirements and specifications referred to in this chapter concerning the following:

SmartTrunk (Section 2.1)

10BASE-T Twisted Pair Network (Section 2.2)

100BASE-TX Twisted Pair Network (Section 2.3)

The network installation must meet the requirements to ensure satisfactory performance of this equipment. Failure to do so will produce poor network performance.

NOTE

The Cabletron Systems SmartTrunk User’s Guide and Cabling Guide referred to in the following sections can be found on the Cabletron Systems World Wide Web site: http://www.cabletron.com/

2.1SmartTrunk

To connect the 2H253-25R to a network so it can take advantage of the SmartTrunk feature, there are certain rules concerning port connections and configurations that must be followed for proper operation. Refer to the Cabletron Systems SmartTrunk User’s Guide for additional information.

2.210BASE-T NETWORK

When connecting a 10BASE-T segment to any of the 2H253-25R ports (1 through 24), ensure that the network meets the Ethernet network requirements of the IEEE 802.3 standard for 10BASE-T. The ports support Category 3 UTP cabling when connected to a 10BASE-T segment. Refer to the Cabletron Systems Cabling Guide for details.

NOTE

If a port is to operate at 10 and 100 Mbps, Category 5 cabling must be used. Refer to Section 2.3 for information about 100BASE-TX networks and cabling.

Network Requirements

2-1
