Preset button and LED — The Preset button and LED have two primary functions (•) and three secondary (❏) functions:

•Activates Save Preset mode to save a configuration as a preset and Recall Preset mode to activate a previously-defined preset.

•Blinks when Save Preset mode is active and lights steadily when Recall Preset mode is active.

❏With the Enter, View, and Esc buttons, selects Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

❏Selects 19200 baud for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

❏Indicates that the RS-232/RS-422 port is set to 19200 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

View () button and LED — The View () button and LED have two primary functions (•) and six secondary (❏) functions:

•Selects a View-onlymode that displays the current configuration.

View-only mode also provides a way to mute and unmute the outputs. See “Muting and unmuting video and/or audio” on page 3-18.

•Indicates that View-onlymode is active.

❏(HVA models) Decreases the audio level of the selected input. See “Viewing and adjusting the input audio level (HVA models)” on page 3-24.

❏(HVA models) Indicates a negative (attenuation) audio level. See “Viewing and adjusting the input audio level (HVA models)” on page 3-24.

❏(HVA models) Decreases the volume of the selected output. See “Viewing and adjusting the output volume (HVA models)” on page 3-29.

❏With the Enter, Preset, and Esc buttons, selects Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

❏Selects 38400 baud for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

❏Indicates that the RS-232/RS-422 port is set to 38400 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-37.

CrossPoint 300 Matrix Switchers • Operation

3-5
