Select the lamp saver mode

•Using the remote control.

Press SmartEco and Highlight Lamp Mode and press / to select Normal/ Economic/SmartEco.

•Using the OSD menu.

1.Press MENU/EXIT and then press /

until the SYSTEM SETUP: Advanced menu is highlighted.

2. Press to highlight Lamp Mode and press MODE/ENTER. The Lamp Settings page displays.

3.Highlight Lamp Mode and press / to

select Normal/Economic/SmartEco.The lamp brightness vary from the different lamp mode,see the description list in table below.

	Lamp Mode	Description

	Normal	100% lamp brightness.

	Economic	Saves 20% lamp power consumption.

	SmartEco	Saves up to 70% lamp power consumption depending on the content
	SmartEco	brightness level.
		brightness level.

If the Economic mode or SmatEco mode is selected, the light output will be reduced and result in darker projected pictures.

Operation 47
