CBM-270 User’s Manual

settings by performing self-printing.

Jumper Wires

	No.	Function	Short	Open	Upon
	No.	Function	Short	Open	Shipment
					Shipment
	J1				Short
	J2	International character	See Table 3		Short
	J3				Short
	J4	Data bit length	7 bits	8 bits	Open
	J5	Unused	−	−	Open
	J5	Unused			Open
	J6	Label detection	Black mark	Label interval	Open
	J7	Unused	−	−	Open
	J7	Unused			Open
	J8	Communication error mark	Ignored	"?" printed	Open

∗J4: Serial interface only. Disabled for the parallel one.

∗J5∼J7: Do not change the shipment settings.

Table 3

No.	USA	France	Germany	U.K.	Denmark-I	Sweden	Italy	Japan
J1	Short	Open	Short	Open	Short	Open	Short	Open
J2	Short	Short	Open	Open	Short	Short	Open	Open
J3	Short	Short	Short	Short	Open	Open	Open	Open

CAUTION:

1) Never change the settings of the jumper wires.

2)If you want to change their settings, consult us.

3)Never disassemble the printer body. It could cause trouble, etc.

Image 33
