Page 22

Chapter 2 The Configuration Menu

Page Format

(from the

previous page)

Form Length

Abs. Length IN 11.0* inches (0.1-24)

Abs. Length MM 279.4* mm (0.1-609.6) Funct. of Lines

66* lines (1-192)

Form Width

Abs. Width IN 13.6* inches (0.1-13.6)

Abs. Width MM 345.4* millimeters (0.1-345.4)

Funct. of CPI 163* Characters (1-272)

Margins

Left Margin 0* columns (0-369)

Right Margin 0* columns (0-369)

Bottom Margin 0* lines (0-451)

Perforation

Skip

Disable* 1/2 inch 2/3 inch 5/6 inch 1 inch

CPI/LPI Select

This parameter lets you specify the characters per inch (cpi) and lines per inch (lpi) values. The defaults are:

•Select CPI - 10.0 cpi

•Select LPI - 6.0 lpi

•DBCS CPI - 6.0 cpi

Host Command

•Enable. The default. Enables all host printing commands.

•Ignore All. This function treats all control codes and printing commands as the data.

•Ignore CPI. This function ignores the CPI selection commands only (e.g., ESC M, ESC P, and ESC G).

•Ignore LPI. This function ignores the LPI selection commands only (e.g., ESC 2 and ESC 0).

•Ignore Unidir. All unidirectional commands sent by the host are ignored by the printer.

•Ignore Pg. Fmt. This function ignores all page format setting commands sent from the host.

22

Image 22
