6. OSD Menu Setup

The OSD menu is composed in hierarchy architecture, it allows you to configure the DVR-16/IP according to the applictation enveironment. Many options can be selected via the operation of the OSD menu.

To enter this OSD menu, press the MENU button of the front panel, then the OSD menu will appear with a highlight cursor over the first item. The cursor can be moved by the up and down buttons.

If you want to exit the OSD menu, you may either 1)select the last item “EXIT” and then press ENTER button; or 2)press ESC button of the front panel directly.

MAIN MENU

1 Event List

2 OSD / Timer

3Monitor

4Camera

5Record

6Event

7Others

8Save / Load Default

9Engineer

10Engineer

11Exit

6.1 Event List

The item allows you to enter the Event List. Up to 255 events will be logged using non-volatile memory. The memory architectrue is “First In First Out”, so always the latest events remain on the list.

6.2 OSD/ Timer

This menu allows you to set the current date/ time, and other On-Screen-Display (OSD) parameters. You can press the ENTER button to enter the sub-menu.

		Event List
1	02/10/20	08:12:39	L16
2	02/10/22	12:38:21	A3
3	02/10/22	15:58:53	M12
		---Continue---
	OSD / Timer
1	Date/ time
2	Date Display Mode		Y/M/D
3	Date/ Time Display		2 Rows
4	Date/ Time Position
5	RS485 Time Calibration
6	Call monitor Dwell		5
7 Text Color			7
8	Display Type		1
9	OSD Display		T&D/T

10 Exit

6.2.1 Date/ Time

Item 1~7 allow you to set the date and time, use the right/ left buttons to adjust the DVR-16/IP to local time.

If you want to save the modification(s), move the cursor to 8 Exit/ Update and press Enter button, the adjusted setting(s) will be memorized. If you don’t want to save the modifications, move the cursor to 9 Exit / Without Update and press Enter button, the adjusted setting(s) will be discarded.

	Date / Time
1 Year		2002
2	Month	12
3 Day		4
4	Hour	16
5	Minute	5
6	Second	20
7 Week		MON
8	Exit / Update
9	Exit / Without Update

6.2.2 Date Display Mode

This item allows you to select a format of date OSD display. You can use right/ left buttons to choose the select from: Y/M/D, M/D/Y and D/M/Y.

6.2.3 Date/ Time Display

This item allows you to select one or two rows for Date /time OSD display.
