Main Menu (continued)

Sub menu	Settings	Description
I-P MODE*2*6	MODE2	Selects IP conversion mode. (	page 27, “IP mode”) Both the main
	MODE1	window and sub-window can be set up in the split-screen display of
		the “TWO WINDOW” function.
		<MODE2> Inter-field interpolation
		<MODE1> Inter-frame interpolation
MONO*2	OFF	Switches between color and monochrome (MONO).
	ON	<OFF> Color	<ON> Monochrome
		• When ON, the CHROMA setting of the picture/volume adjusting menu
		is fixed at 0.
ANAMO*2*8	OFF	With an Anamo lens and HD-SDI input, the picture is resized to
	ON	Anamo magnification (the vertically enlarged signal can be vertically
		compressed and corrected for display). This function is not available in
		the split screen display of the “TWO WINDOW” function.
SD ASPECT*2	4:3	Sets the aspect ratio for SD signal input. This function is not available
	16:9	in the split screen display of the “TWO WINDOW” function.
		<4:3> 4:3 display	<16:9> 16:9 display
SCAN*2	NORMAL	Sets under-scan and normal display. This function is not available in
	UNDER	the split screen display of the “TWO WINDOW” function.
		<NORMAL> Normal display	<UNDER> Under-scan
COLOR GAIN R	0 - 30	Fine tunes R component GAIN in split-screen mode and sub-window
		display (single screen) of the “TWO WINDOW” function.
COLOR GAIN G	0 - 30	Fine tunes G component GAIN in sub-window input in the split-screen
		display and sub-window display (single screen) of the “TWO
		WINDOW” function.
COLOR GAIN B	0 - 30	Fine tunes B component GAIN in sub-window input in the split-screen
		display and sub-window display (single screen) of the “TWO
		WINDOW” function.

*2	These functions are not available when “RGB-COMP.” under “YPBPR/RGB” or “DVI-COMP.” under “DVI-D” is
	selected in the “INPUT SELECT” menu ( page 36). The gamma curve is set to STANDARD when “RGB-
	COMP” or “DVI-COMP” is selected. Selecting WIDE1 to 3 for “COLOR SPACE” produces the gamma curve
	fixed to that “COLOR SPACE.”
*6	To use the “TWO WINDOW” ( page 34) function,

1)Change settings after exiting the “TWO WINDOW” function.

2)It is recommended to use “MODE2” for handling fast video. *8 “SCAN” changes are not reflected in Anamo size display.

IP mode

“MODE1” performs IP conversion using inter-frame interpolation. The factory default is “MODE1”.

“MODE2” performs IP conversion using inter-field interpolation.

Since interpolation is performed inside each field, this mode is suitable for checking interlace status.

27
