JVC HR-J631T Code Timer Programming, Access G-CODE Screen, Enter G-CODE Number, Check Input Data

Page 28

G-CODE

PRESS NUMBER KEY(0-9)

PRESS (MENU) TO MAIN MENU

28TIMERRECORDING(cont.)

G-Code Timer Programming

Before G-Code Timer programming, see "G-Code Setup" on page 9.

OK

6

q

1

2

3

LOAD A CASSETTE

Make sure the record safety tab is present.

●The VCR’s power comes on automatically.

●If you’re watching on channel 13, press TV/VIDEO to select the VIDEO mode. VIDEO is displayed on the front display panel.

ACCESS G-CODE SCREEN

Press MENU on the remote control.

●The clock must be set in order to access the G- Code screen. If you

haven’t set the clock, the Main Menu screen appears when you press

MENU. Refer to page 5 for the clock setting proce- dure.

ENTER G-CODE NUMBER

Press the appropriate NUMBER keys to enter the G-Code number printed in the TV listings for the TV program you wish to record.

SP/EP

TV/VIDEO
	1		2	3
NUMBER	4		5	6
NUMBER
	7		8	9
CANCEL		"8"	0
CANCEL
	NUMBER
	NUMBER
				OK

NUMBER "9"

MENU

TV/VCR

4

5

●To make corrections, press CANCEL and input the correct G-Code number.

●If the G-Code number you input is incorrect, "ERROR" may appear on the screen to advise you of the error. This happens when the G-Code number is for a program which has already passed. "ERROR" is displayed for about 4 seconds and the G-Code screen reappears (step 2).

CHECK INPUT DATA

	Press OK and the Program	PROGRAM 1
	screen appears.	PROGRAM 1
	screen appears.	(G-CODE 12345678)
	The G-Code number you	DATE	7/10 WED
	entered appears in the	START	8:00 PM
	entered appears in the	STOP	9:00 PM
	Program screen. Check to	CHANNEL	8 SP

	make sure it’s accurate.	PRESS (8=DAILY, 9=WEEKLY
		SP/EP=REC SPEED)
	● To timer-record daily or	SP/EP=REC SPEED)
	● To timer-record daily or	PRESS (MENU) TO END
	weekly serials, press

DAILY (NUMBER “8”) or WEEKLY (NUMBER “9”). “DAILY” or “WEEKLY” appears on the Program screen.

●If you made a mistake, press CANCEL and, after pressing MENU as many times as necessary to access the G-Code screen, input the correct G-Code number.

SET TAPE SPEED

Press SP/EP.

Image 28
