Panasonic AW-HE870N operating instructions When an SDI card AW-HHD870 has been installed

Page 28

System configuration (Connections)

Connection of the Indoor Pan-tilt Head AW-PH360 (continued)

When an SDI card (AW-HHD870) has been installed

Use a coaxial cable to connect the SDI OUT connector on the SDI card and the SDI IN connector on the AW-PH360.

Use a coaxial cable to connect the Pr/SDI OUT connector on the AW-PH360 to the SDI input connector on the color monitor.

Notes

HD (1080i or 720p) analog component signals cannot be output from the AW-PH360.

Refer to the operating instructions of the AW-PH360 for details relating to internal switch settings, etc. of the pan-tilt head.

Use the AW-LZ17MD9AG lens when using the camera mounted on the pan-tilt head AW-PH360. Lenses other than the AW-LZ17MD9AG cannot be used.

Do not mount the camera on the AW-PH360 when the AK-LZ20M85G is installed. Weight balance cannot be secured.

AW-IF400 Switch settings (when the AW-RP400 is used)

SW1

SW2



SET UP



1

2

3

4





OFF

ON

OFF

ON

OFF

OFF

- 28 -
