Samsung SPD-1000 user manual Precautions, Persons is not recommended

Page 5

Precautions

Installation by unqualified

If any unusual odors or smoke comes

ENGLISH

persons is not recommended.

from the camera, stop using the product.



Experienced and skilled technicians have to install

It may cause fire.



this product. Unqualified and personal installation





may cause fire or electric shock. Contact the dealer





for installation.





Do not install the product under humid conditions

Install the product in a place strong



or near flammable or explosive gases.

enough to hold it.



Do not install the product in too



Do not install the camera in

hot or too cold environments.



intermittent lighting environments.

Do not use the camera under extreme temperatures (below -

Do not install the camera under severely

10° or above +50°). It may cause poor image quality or

changing lighting environments such as

failure. Be especially careful to provide ventilation when

fluorescent lamps. It may cause the camera

operating the camera under high temperatures.

to work improperly.











Never drop the camera or subject





Do not aim the camera at the sun



it to severe shocks or vibrations.





or any other strong light source.

It may cause failure, electric shock or fire.

The product may fall.











Do not handle the power plug



Do not disassemble or insert



with wet hands.



foreign objects.

It may cause electric shock.

It may cause failure or electric shock.

It may cause failure.

Do not touch the front glass of the camera.

It is the most important part of camera. Be careful not to mark it with fingerprints.

It may cause fatal damage to CCD device or internal circuit.

Do not install the camera where it might be exposed to rain, water or spillages.

If the camera gets wet, it may cause failure.
