Using the timedbaking and



roasting features(upperovenonly).

GEAppliances.com

NOTE: Foodsthat spoil easily—such as milk, eggs, fish, stuffings,poultryand pork—shouldnot be allowedto sit for more than 1 hour beforeor after cooking. Roomtemperaturepromotes the growth of harmful bacteria. Be surethat the oven light is off because heat from the bulb will speedharmfulbacteriagrowth.

How to Set an Immediate Start and Automatic Stop

Safety Instructions

The upper oven will turn on immediatelyand cook for a selected lengthof time. At the end of the cooking time, the oven will turn off automatically.

Touch the BAKE pad.

Using the number pads, enterthe desired temperature.

Touch the COOKING TIME pad.

NOTE: If your recipe requirespreheating,you may need to add additional time to the length of the cooking time.

Using the number pads, enterthe desired baking time. The oven temperature and the cooking time that you entered will be displayed.

Touch the START pad.

The word ON and 100° will be displayed. The cook time will begin to count down. As the oven heats up, the display will show the changing temperature. When the oven reaches the temperatureyou set, 3 beeps will sound.

At the end of timed baking, the oven will turn off. The end of cycle tone will sound.

Touch the CLEAR/OFF pad to clear the display.

Operating Instructions

How to Set a Delayed Start and Automatic Stop

You can set the upperovencontrol to delay- start the oven, cook for a specific lengthof time and then turn off automatically.

Makesure the clock shows the correct time of day.

Touch the BAKE pad.

Using the number pads, enterthe desired temperature.

Touch the COOKING TIME pad.

NOTE: If your recipe requirespreheating,you may need to add additional time to the length of the cooking time.

Using the number pads, enterthe desired baking time.

Touch the DELAYSTART pad.

Using the number pads, enterthe time of day you want the oven to turn on and start cooking.

Touch the START pad.

If you would like to check the times you have set, touch the DELAYSTART pad to check the start time you have set or touch the COOKING TIME pad to check the length

of cooking time you have set.

The oven will turn on automatically.

The word ON and 100° will be displayed. The cook time will begin to count down.

As the oven heats up, the display will show the changing temperature. The oven will cook for the programmed cooking time and shut off automatically.

At the end of timed baking, the oven will turn off. The end of cycle tone will sound.

Touch the CLEAR/OFF pad to clear the display.

Troubleshooting Tips Consumer

NOTE: An attention tone will soundif you are usingtimed baking and do not touch the START pad after entering the baking temperature.
