GSS Series User Manual

1.4.1 User interfaces on the front panel

The front panel of the GSS-16T4SFP and GSS-24T4SFP consists of 16x or 24x 10/100/1000Mbps Copper Gigabit Ethernet ports, 4x SFP fibre ports and 1x reset button to restore factory configuration.

LED Display	Gigabit
Panel	Ethernet Ports

Factory

Default ButtonSFP Fibre

Ports

Fig. 1.3 Front Panel of the GSS-16T4SFP

LED Display

Panel

Gigabit

Ethernet Ports

Factory

Default Button

SFP Fibre

Ports

Fig. 1.4 Front Panel of the GSS-24T4SFP

Alloy Computer Products Pty Ltd Copyright ©2007

7
