GSS Series User Manual
Apply Button: The Apply button must be pressed after making any changes to any of
the values on this screen.
Port Config: Used to configure per port parameters.
Fig. 3.7
Port: Is the physical port number of the switch.
Ingress Filtering
Enabled: Tick the check box to enable Ingress Filtering.
Packet Type: Select each port to accept All types of packets including tagged and
untagged packets, or only allow each port to accept Tagged packets.
Tag Out Enabled: Tick this check box to enable all packets being sent from this port to be
tagged. If you are enabling this feature please ensure that the connecting
device can accept tagged packets.
PVID: Select the desired PVID from the drop down box provided.
Apply Button: The Apply button must be pressed after making any changes to any of
the values on this screen.
Cancel Button: By pressing the cancel button, you will discard any changes that you
have made.
Alloy Computer Products Pty Ltd Copyright ©2007
23
