Removing and Installing Parts 133
Installing a Floppy Drive
1
Follow the procedures in "Before You Begin" on page 99.
2
Remove the computer cover (see "Removing the Computer Cover" on
page 101).
3
Remove the bezel (see "Removing the Bezel" on page 122).
4
Remove the optical drive (see "Removing an Optical Drive" on page 140).
5
Remove the FlexBay drive insert (see "Removing the FlexBay Drive Panel
Insert" on page 135).
6
Press the two spring clamps and slide out the FlexBay drive cage from the
front of the system.
7
Align the screw holes in the floppy drive with the cage notch and place the
floppy drive in the FlexBay drive cage.
1 screw holes in the floppy drive 2 cage notch (2)
3 spring clamps (2) 4 screws (2)
3
2
1
4
