XDVD700 OPERATION
Troubleshooting
Problem | Cause | Action |
Unit will not turn on | Yellow wire not connected or incorrect voltage | Check connections for proper voltage (11~16VDC) |
(no power) | Red wire not connected or incorrect voltage |
|
|
|
|
| Black wire not connected | Check connection to ground |
| Fuse blown | Replace fuse |
Unit has power | Speaker wires not connected | Check connections at speakers |
(but no sound) | One or more speaker wires touching each | Insulate all bare speaker wires from each other and chassis |
| ||
| other or touching chassis ground | ground |
|
|
|
Unit blows fuse | Yellow or red wire touching chassis ground | Check for pinched wire |
| Speaker wires touching chassis ground | Check for pinched wire |
| Incorrect fuse rating | Use fuse with correct rating |
Unit has audio | Parking brake safety circuit not connected | Check connections at parking brake |
(but no video) | Parking brake not applied | Apply parking brake as described on page 34 |
|
|
|
No video display | Reverse circuit not connected | Check connections at reverse lamp |
(when in reverse) | Vehicle is not in reverse | Select reverse gear |
DVD does not start playback | Physical defect in media | Check media for scratches |
| Wrong region | Use discs labeled "Region 1" or "All" only. |
|
|
|
IR remote does not work | Dead battery | Replace battery |
|
|
|
Excessive skipping | Unit is not mounted correctly | Check mounting sleeve |
|
|
|
| Physical defect in media | Check media for scratches |
Bad Disc appears | Focus error or disc is in upside down | Press eject or RESET |
on display |
|
|
|
|
|
Incorrect Region Code | Region code error | Use only DVDs labeled “Region 1” or “All” only. |
appears on display |
|
|
Front panel will not | Front panel obstructed | Remove the obstacle and press OPEN again to resume the |
open/close |
| monitor open/close sequence. |
|
|
|
53
