ACCESSORIES

COIL ACCESSORIES

COIL MODEL

TX2N4 TXV KIT

TX3N4 TXV KIT

TX5N4 TXV KIT

FSK01A FREEZE PROTECTION KIT











CA*F18246*

X

X



X

CA*F30306*



X



X

CA*F36426*



X

X

X

CHPF18246*





X

X

CHPF30306*





X

X

CHPF36426*





X

X

CSCF1824N6*

X





X

CSCF303N6*



X



X

CSCF3642N6*



X

X

X

HKR SERIES ELECTRIC HEAT KITS

ELECTRIC HEAT KITAPPLICATIONS - MBR & MBE

BLOWER











ELECTRIC HEAT KIT































NO HEAT

HKR-03*

HKR05-(C)'

HKR-06*

HKR-08(C)*

HKR-10(C)*

HKR-15(C)*

HKR-20(C)*

HKR-21(C)*

^HKR3-15*

^HKR3-20A



MBR0800AA-1AA

-

X

X

X

X

X



































MBR1200AA-1AA

-

X

X

X

X

X

X

X

X

X

X

























MBR1600AA-1AA

-

X

X

X

X

X

X

X

X

X

X

























MBR2000AA-1AA

-

X

X

X

X

X

X

X

X

X

X

























MBE1200AA-1AA

-

-

-

-

X

X

X

-

-

-

-

























MBE1600AA-1AA

-

-

-

-

-

X

X

-

-

-

-

























MBE2000AA-1AA

-

-

-

-

-

X

X

X

-

-

-

























MBE1200AA-1BA

-

X

X

X

X

X

X

-

-

-

-

























MBE1600AA-1BA

-

X

X

X

X

X

X

-

-

-

-

























MBE2000AA-1BA

-

X

X

X

X

X

X

X

-

-

-

X = Allowable combinations

^ = Circuit 1:

Single Phase for Air Handler Motor

- = Restricted combinations

Circuit 2:

3-Phase for HKR3 Heater Kits

*= Revision level that my or may not be designated C = Circuit Breaker option

ELECTRIC HEAT KITAPPLICATIONS - ARPF



ARPF1824

ARPF1931

ARPF3030

ARPF3642

ARPF3743

ARPF4860



1/16

1/16

1/16

1/16

1/16

1/16

HKR-03*

X

X

X

X

X

X

HKR-05*, HKR-05C*

X

X

X

X

X

X

HKR-06*

X

X

X

X

X

X

HKR-08*, HKR-08C*

X1

X1

X

X

X

X

HKR-10*, HKR-10C*

X1

X1

X1

X

X

X

HKR-15C*

X2

X2

X2

X3

X3

X

HKR-20C*





X2

X3

X3

X

HKR-21C*





X2

X3

X3

X

^ HKR3-15*





X2

X3

X3

X

^ HKR3-20*





X2

X3

X3

X

*

Revision level that may or may not be designated

¹ Air handler must either be on medium or high speed

C

Circuit breaker option

²

Air handler must be on high speed

^

Heat kit requires three-phase power supply

³

For static pressure of 0.6 or higher, air handler must be on







medium or high speed
