Custom functions

The SB-800 can easily set, activate, or cancel various operations using the Custom settings as shown below. Icons appearing on the LCD panel vary depending on the settings and the camera/lens combinations. No icon appears when the settings are not available.

For details on setting custom functions, see “Custom settings” (p. 68).

■■■ Available Custom functions and the icons

ISO sensitivity (p. 24)

Wireless flash mode (p. 72)

Sound monitor in the wireless flash mode (p. 89)

Non-TTL auto flash mode (p. 38)

Standby function (p. 21)

Selecting the distance unit of measure (m, ft)

Power zoom function (p. 26)

Power zoom function using the built-in wide- flash adapter/Nikon Diffusion Dome (p. 27)

LCD panel illuminator (p. 119)

LCD panel brightness (p. 119)

Wide-area AF-Assist Illuminator (p. 62)

Canceling flash firing (p. 62)

Other functions

67

Image 67

Nikon SB-800 instruction manual Available Custom functions and the icons
