RedMax G5300 manual

A

			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	503 86 37-05	FUEL TANK ASSY	1
2	537 35 95-01	•TANK VENT ASSY	1
3	503 85 44-02	•THROTTLE LOCKOUT	1
4	503 99 86-01	•RECOIL SPRING	1
5	503 85 45-02	•THROTTLE TRIGGER	1
6	720 18 25-20	•PIN	1
7	544 32 50-02	FUEL HOSE	1
8	503 44 32-01	FILTER	1
9	503 21 88-76	SCREW	2
10	503 85 41-01	ANTIVIBRATION ELEMENT	2
11	544 32 49-20	FUEL HOSE	1
12	537 21 52-01	TANK CAP ASSY	1
13	503 57 89-01	•HOLDER	1
14	537 21 50-01	•SEALING	1
B
			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	503 21 88-76	SCREW	3
2	537 30 17-03	HANDLE	1
3	503 92 24-02	SPACER	1
4	503 89 83-01	ANTIVIBRATION ELEMENT	1
5	503 21 88-72	SCREW	2
C
			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	521 89 39-01	HAND GUARD ASSY	1
2	537 15 27-01	•HEAT PROTECTOR	1
3	503 92 95-01	WEAR WASHER	1
4	503 89 30-03	SCREW	2
5	537 02 99-01	WEAR PROTECTION	1
6	505 15 59-02	CHAIN BRAKE ASSY	1
7	503 89 29-01	•PIN KNEE-JOINT	1
8	503 21 70-10	•SCREW CCRPANT	1
9	503 89 08-02	•KNEE JOINT ASSY	1
10	503 46 59-01	•BRAKE SPRING	1
11	735 31 08-20	•E-CLIP	1
12	537 04 30-01	•BRAKE BAND ASSY	1
13	503 85 52-01	•GUIDE BUSHING	1
14	503 21 70-72	•SCREW CCRPANT	5
15	537 10 80-02	•CAP	1
16	537 08 90-01	•WEAR PROTECTION	1
17	503 85 66-01	•COVER PLATE	1
18	510 10 07-02	•LABEL	1
19	503 22 00-01	•NUT FLANGE	2

G5300 (810)

D

			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	503 89 06-01	AIR CONDUCTOR	1
2	505 24 76-02	STARTER ASSY	1
3	505 30 51-25	•STARTER CORD	1
4	503 21 77-16	•SCREW	1
5	503 21 28-10	•SCREW CCRPANT	2
6	537 09 25-01	•STARTER PULLEY	1
7	537 09 31-01	•SPRING CASSETTE ASSY	1
8	544 37 65-01	•STARTER HANDLE	1
9	505 25 97-01	•STARTER HOUSING	1
10	544 08 03-01	•SCREW	4
11	510 10 06-02	LABEL	1
E
			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	521 88 68-01	CYLINDER COVER ASSY	1
2	501 63 97-01	•COVER	1
3	503 84 59-01	•HEAT PROTECTOR	1
4	522 51 14-01	•LABEL	1
F
			QTY/
Key#	PART NUMBER	DESCRIPTION	UNIT
1	503 21 74-12	SCREW	3
2	537 40 56-01	CHAIN GUIDE PLATE	1
3	537 14 65-01	BELLOWS	1
4	503 86 93-01	CARBURETTOR MOUNTING	2
5	503 21 75-12	SCREW	4
6	544 36 07-03	CARBURETTOR AREA BASE	1
7	537 17 19-07	CRANKCASE ASSY	1
8	503 20 07-76	•SCREW	3
9	537 04 03-01	•VALVE	1
10	721 12 07-30	•PIN	1
11	503 20 08-32	•SCREW IHSCM	6
12	503 21 51-01	•SCREW	2
13	503 86 92-01	•LATERAL SUPPORT	2
14	503 90 56-01	•GUIDE BUSHING	1
15	503 87 54-01	•BAR BOLT	2
16	503 90 56-01	•GUIDE BUSHING	1
17	503 20 25-16	SCREW IHSCM	2
18	503 43 65-01	POSITION SPRING	1
19	503 89 24-01	LOCK	1
20	503 93 04-01	BUMPER	1
21	503 90 59-01	SPIKE	1
22	537 07 12-01	CHAIN TENSIONER	1
23	503 88 63-01	CHAIN CATCHER PIN	1
24	544 33 10-01	HOSE	1
25	504 01 09-01	LINING	1
26	504 07 15-05	BRACKET	1
27	503 93 66-01	PRIMER HOUSING	1
28	544 44 97-01	SCREW	1
29	503 89 47-04	SNAP	3
30	503 88 86-01	AIR NOZZLE	1
31	503 21 39-01	SCREW	3
32	537 28 15-02	TANK CAP ASSY	1
33	503 57 89-01	•HOLDER	1
34	501 62 68-01	•GASKET	1
A	503 94 28-02	GASKET KIT	1
