Suunto D6I instruction

By pressing the UP/DOWN buttons, you can scroll the no-decompression limits in 3 m/10 ft increments ending at 45 m/150 ft. No-decompression limits longer than 99 minutes are displayed as “—“.If the O2% is too high for the planned depth, NA is dis- played instead of a numerical no-decompression limit.

WHEN ENTERING THE PLAN MODE

THE DISPLAY FIRST BRIEFLY SHOWS THE

REMAINING DESATURATION TIME BEFORE

GOING INTO PLAN MODE. USE UP AND

DOWN BUTTONS TO SCROLL DIFFERENT

NO-DECOMPRESSION LIMITS.

NO-DECOMPRESSION LIMITS LONGER

THAN 99 MINUTES ARE DISPLAYED AS “–”.

The Planning mode takes into account the following information from previous dives:

•any calculated residual nitrogen

•all dive history for the past four days

The no-decompression times given for different depths will therefore be shorter than before your first “fresh” dive.

You can exit the DIVE PLANNING mode by pressing the MODE button.
