Keyboard and PS/2 KB/ mouse connections (KB CON, KB/PS2 MOUSE)

The SBC-455 board provides two keyboard connectors. A 5-pin connector (KB CON) supports passive backplane applications. A second 6-pin mini-DIN connector (KB/PS2 MOUSE) on the card mounting bracket supports single board computer applications. The card comes with an adapter to convert the 6-pin mini-DIN connector, used for the mouse, to the standard DIN connector for the keyboard.

Keyboard connector (KB CON)

Pin	Function
1	K.B. clock

2	K.B. data

3	N.C.
4	GND
5	+5 VDC

Keyboard or PS/2 mouse connector (KB/PS2 MOUSE)

Pin	Function
1	K.B. data

2	PS/2 mouse data

3	GND

4	+5 VDC
5	K.B. clock
6	PS/2 mouse clock

Chapter 2 Installation 25
